Ball Nut

Ball Nut, 32 mm X 40 mm, Wiper Included, Round, No Safety Feature, 端盖, 14900 N

仅螺母
经过质量检测，确保可靠的性能
具有可靠的精度和可重复性，且价格实惠

尺寸

Dimension	Value
Unit Of Measure	All length values in: millimeters

dimensions

Dimension	Value
Unit Of Measure	All length values in: millimeters

规格

Specification	Value
Diameter	32 mm
导程	40.0 mm
Nut Material	Alloy Steel
Nut Style	KGM
Wiper	Included
Screw Part Number	0205000347-RL6000
Number Of Starts	4
Total Weight	0.460 kg

性能

Performance

Performance

Performance

Performance	Value
Load, Dynamic	14,900 N (3,350 lbf)
Load, Static	32 kN (7,284 lbf)
