8106-448-007

没有找到想要的产品？请使用产品选择工具

8106-448-007

Ball Nut

Ball Nut, 0.631 in X 0.200 in, Round, No Safety Feature, Non-Preloaded, 捡拾齿, 800 lbf

仅螺母
经过质量检测，确保可靠的性能
具有可靠的精度和可重复性，且价格实惠

尺寸

Dimension	Value
A	43.69 mm (1.720 in)
B	12.83 mm (0.505 in)
C	28.70 mm (1.130 in)
D	34.47 mm (1.357 in)
E	19.99 mm (0.787 in)
F	20.32 mm (0.800 in)
TH	15/16-16 UN-2A

dimensions

Dimension	Value
A	43.69 mm (1.720 in)
B	12.83 mm (0.505 in)
C	28.70 mm (1.130 in)
D	34.47 mm (1.357 in)
E	19.99 mm (0.787 in)
F	20.32 mm (0.800 in)
TH	15/16-16 UN-2A

规格

Specification	Value
Diameter	0.631 in
导程	0.200 in
Nut Material	Alloy Steel
Nut Style	Precision
Screw Part Number	190-9122
Number Of Starts	1
Total Weight	0.50 lbs

性能

Performance	Value
Load, Dynamic	3,559 N (800 lbf)
Load, Static	27,357 N (6,150 lbf)
